uPVC Pressure Pipe
$0.00
uPVC Pressure Pipe manufactured to DIN 8061 / 62. Standerd Length : 5.8 & 6 meters. Socket Type : Solvent Weld or Rubber Seal Ring Produced on request
Description
Standard: uPVC Pipe DIN 8061 / 62
Standard Length: 5.8 & 6 meters
Colour: Grey / Dark Grey / White
Pressure Ratings at 20°C: Series 2 (4 Bar), Series 3 (6 Bar), Series 4 (10 Bar), Series 5 (16 Bar)
Socket Type: Solvent Weld or Rubber Seal Ring Produced on request
Additional information
| Sizes | 20mm (1.7mm Series 5 Wall Thickness), 25mm (1.7mm Series 4, 2.1mm Series 5 Wall Thickness), 32mm (2mm Series 4, 2.65mm Series 5 Wall Thickness), 40mm (2mm Series 3 , 2.1mm Series 4, 3.25mm Series 5 Wall Thickness), 50mm (2mm Series 3, 2.65mm Series 4, 4mm Series 5 Wall Thickness), 63mm (2.1mm Series 3, 3.25mm Series 4, 5.05mm Series 5 Wall Thickness), 75mm (2mm Series 2, 2.45mm Series 3, 3.9mm Series 4, 6mm Series 5 Wall Thickness), 90mm (2mm Series 2, 2.95mm Series 3, 4.65mm Series 4, 7.15mm Series 5 Wall Thickness), 110mm (2mm Series 1, 2.45mm Series 2, 3.5mm Series 3, 5.7mm Series 4, 8.75mm Series 5 Wall Thickness), 160mm (2mm Series 1, 3.5mm Series 2, 5.05mm Series 3, 8.25mm Series 4, 12.6mm Series 5 Wall Thickness), 200mm (2mm Series 1, 4.3mm Series 2, 6.3mm Series 3, 10.2mm Series 4, 15.75mm Series 5 Wall Thickness), 225mm (2mm Series 1, 4.85mm Series 2, 7.05mm Series 3, 11.45mm Series 4, 17.65mm Series 5 Wall Thickness), 250mm (2.2mm Series 1, 5.25mm Series 2, 7.8mm Series 3, 12.6mm Series 4, 19.65mm Series 5 Wall Thickness), 280mm (2.55mm Series 1, 5.9mm Series 2, 8.75mm Series 3, 14.2mm Series 4, 21.95mm Series 5 Wall Thickness), 315mm (2.75mm Series 1, 6.65mm Series 2, 9.8mm Series 3, 15.85mm Series 4, 24.7mm Series 5 Wall Thickness), 400mm (3.5mm Series 1, 8.4mm Series 2, 12.4mm Series 3, 20.2mm Series 4, 31.3mm Series 5 Wall Thickness) |
|---|---|
| Color | Gray, Dark Grey, White |
